CO2 lasers can be used for applications requiring precision and mass production. These machine engravers and cutters are highly precise and can be used to create designs, decorations, and the like on just about any non-metal you can think of, including wood, plastic, and paper, to name a few. The beam doesn’t physically touch the material it is working with; instead, it causes the material to melt through intense heat. This causes minimal damage to the material and the machine.
CO2 lasers can be used for applications requiring precision and mass production. These machine engravers and cutters are highly precise and can be used to create designs, decorations, and the like on just about any non-metal you can think of, including wood, plastic, and paper, to name a few. The beam doesn’t physically touch the material it is working with; instead, it causes the material to melt through intense heat. This causes minimal damage to the material and the machine.
| Model | C1390 | C1313 | C1410 | C1610 |
|---|---|---|---|---|
| Power Source | 100-150 | 100-150 | 100-150 | 100-150 |
| Working Area (mm) | 1300 x 900 | 1300 x 1300 | 1400 x 1000 | 1600 x 1000 |
| Max. Speed (mm/sec) | 600 | 600 | 600 | 600 |
| CO2 Laser Source | Sealed Glass Laser Tube | Sealed Glass Laser Tube | Sealed Glass Laser Tube | Sealed Glass Laser Tube |
| Weight (kg) | 320 | 360 | 330 | 360 |
| Outer Dimensions (mm) | 1860 x 1475 x1100 | 1860 x 1865 x 1100 | 1960 x 1555 x 1100 | 2160 x 1555 x 1100 |
AC servo / stepper motor technology for high speed and high precision movement control.
Red beam dot pointer to help you see the expected laser beam position for cutting and engraving.
Processing file path is displayed simultaneously when the machine runs.
USB flash drives support reading files directly from USB flash drives without the use of a computer.
Power brake function: continue work after power off.
High-quality chiller unit for beer performance and long-life laser tube.
The machine is provided with foot-mounting lags so that there is no vibration in the machine, and the machine can be adjusted to zero level.
The machine is provided with a heavy-duty compressor that has an air-assist combining adjustable
focus. Systems in coaxial jet air to prevent cung edge from burning down.
